Hyperion 200

Hyperion 200

Managed industrial Ethernet switch with PTPv2 time synchronization server function and 4x 1/2,5/10 Gbps i 8/16x 10M/100M/1G RJ45 PoE÷High PoE IEEE802.3bt  lub 8/16x 100M/1G SFP

Industrial managed Ethernet switch equipped with 4x 1/2.5/10 Gbps and 8/16x 10M/100M/1G RJ45 PoE÷High PoE IEEE802.3bt ++ or 8/16x 100M/1G SFP interfaces

Properties and Benefits

  • A family of industrial switches featuring 4x 10/2.5/1Gbps SFP/SFP+ slots and 8/16x 10M/100M/1Gbps RJ45 ports or 100M/1Gbps SFP slots
  • Additional NMI UTP RJ45 10 / 100Mbit / s management port
  • ITU-T G.8032 ERPS support, connection reconfiguration in <20ms, up to 64 rings simultaneously
  • Support for STP, RSTP and MSTP protocols
  • IEEE802.1x authentication, Radius, Tacacs+ - AAA
  • Support for PRP (IEC 62439-3 Clause 4) or HSR (IEC 62439-3 Clause 5) on ports in the R module.
  • The following IEEE1588 v.2 (PTPv.2)-based precision time synchronization profiles are available in the HYPERION-200.2 hardware-supported version: 1588 default, G.8265.1 and G.8275.1
  • NTP protocol in server/client mode and SNTP
  • Switch designed in accordance with the requirements of IEC61850-3, IEEE1613 standards for substations
  • As standard, secondary surge protection in UTP modules on RJ-45 ports only in the transmission path, ITU-T K.44 4kV 10/700us
  • Management IPv4, IPv6, Web, telnet, SSH and local CLI (RS232), SNMP v1,2,3
  • Access security SNMPv3, HTTPS, SSH
  • DDMI - SFP module monitoring function
  • Energy Saving with Energy Efficient Ethernet (EEE).
  • Ethernet OAM support (Link OAM and Service OAM)
  • Standard equipped with I/O interfaces: interface 4 inputs and 2 outputs 'cc' for monitoring, alarms and control purposes
  • Operating temperature: -40 to +85°C when conditions are met
  • Rugged metal housing for mounting on a DIN rail
  • Power supply 36-60 VDC or 80-360 VDC / 75-270 V AC

Optional features

  • L3 routing support - static routing
  • PoE ÷ PoE ++ support up to 90W per UTP port (on all ports max. 500W), Watchdog PoE

Optional features included with the license

  • Extension with the IEEE 1588-2008v.2 (PTPv2) Power Profile protocol; real-time synchronization for energy applications in accordance with IEEE C37.238-2011, C37.238-2017 standards; IEC61850-9-3,
  • Activation of the Synchronous Ethernet function G.8261


Thanks to its reliability, Hyperion 200 is used in industries such as:

Catalog card

Ethernet Switch Hyperion-200

Product card

Haven’t found the answer to your bothering questions?

  • Supported transmission standards
    IEEE 802.3 10Base-T Ethernet
    IEEE 802.3u 100Base-TX Fast Ethernet
    IEEE 802.3u 100Base-FX Fast Ethernet Fiber
    IEEE 802.3ab 1000Base-T Gigabit Ethernet
    IEEE 802.3ae 10GBASE-SR / LR / ER / ZR (SFP +) 10 Gigabit Ethernet
    IEEE 802.3z Gigabit Fiber
    IEEE 802.3x Flow Control and Back-pressure
    IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
    IEEE 802.30ah Link OAM
    IEEE 802.1p Class of Service (CoS)
    IEEE 802.1Q VLAN
    IEEE 802.1ad QinQ
    IEEE 802.1d – Spanning Tree Protocol (STP)
    IEEE 802.1w – Rapid Spanning Tree Protocol (RSTP)
    IEEE 802.1s – Multiple Spanning Tree Protocol (MSTP)
    IEEE 802.3ad Link Aggregation Protocol (LACP)
    IEEE 802.1ak Multiple Registration Protocol (MRP, GARP, GVRP)
    IEEE 802.1x Port Based Network Access Protocol, EAP, TACACS+, RADIUS – authentication,
    authorization and accounting functions – AAA
    IEEE 802.3az EEE
    IEEE 802.3af/at type 1/2 and PoE+ up to 30W per port, maximum on all ports 500W
    IEEE 802.3bt High PoE up to 90W per port, 500W maximum on all ports
    ITU K.44 – built-in secondary overvoltage protection on RJ-45 for transmission path, 4kV,
    10/700us compliant: Resistibility tests for telecommunication equipment exposed to
    overvoltages and overcurrents – Basic Recommendatio n
  • Supported protocols
    IPv4, IPv6, ARP, ICMP, TCP, UDP, DNS
    IGMP v1, v2, v3, MLD v1, v2, GMRP, GVRP,
    SNMP v1/v2c/v3,
    DHCP client/server,
    NTP client/server, SNTP,
    IEEE1588 PTP v2 (available only version 200.2),
    Synchronous Ethernet (only available on version 200.2)
    HTTP, HTTPS, Telnet, SSH v2, Syslog,
    EtherNet/IP, SNMP Inform, RMON, LLDP, LLDP-MED
    MIB-II, Ethernet-Like MIB PROFINET Conformance Class A
    IEEE 802.1x Port Based Network Access Protocol, EAP, TACACS+, RADIUS, NAS
  • Supported standards, recommendations and directives EMC, safety *
    PN-EN 55024:2011
    PN-EN 60825-1:2014-11
    PN-EN IEC 62368-1:2020-11
    EMC 2014/30/EU
    LVD 2014/35/EU
    IEC 61850-3:2014
    IEEE 1613-2009
    IEC 61000-4-2
    IEC 61000-4-3
    IEC 61000-4-4
    IEC 61000-4-5
    IEC 61000-4-6
    IEC 61000-4-8
    IEC 61000-4-11
    IEC 61000-4-12
    IEC 61000-4-29
  • Ethernet interfaces
    Ethernet Connectors: 4 x 1G/2.5G/10Gbps SFP+, 8/16x 10/100/1000Mbps RJ45 ports or 8/16x
    100M/1000M SFP slots (100Mbps speed on Optical Interface only works with optical SFP inserts)
    Non-blocking switching matrix: 160Gbps
    Forwarding: 84-72 Mpps depending on the number of ports
    QoS: Support for 8 physical queues, Weighted Round Robin algorithm and Strict Priority queuing.
    Priority settings based on: 802.1p PCP priorities, DSCP/ToS, port-based priority settings, TCP/UDP
    port number-based priority configuration capabilities
    VLANS: 4094 VLAN entries, 802.1Q, 802.1QinQ, private VLANs, VLAN translation.
    Flow Control: Flow Control – controls the sent and received packets to prevent buffer overflow, i.e.
    data loss
    Storm protection: filtering for incoming traffic of Broadcast, Multicast, Unknown DA or all packets,
    outgoing traffic filtering for packets of all types, bandwidth limiting
    Security: HTTP/HTTPS, SSL/SSH, IEEE 802.1x Port Based Network Access Protocol, EAP, TACACS+; RADIUS authentication, authorization and accounting functions – AAA
    IGMP snooping: V1/V2/V3, IGMP Filtering/Throttling, IGMP query, IGMP proxy reporting, MLD
    snooping V1/V2
    Syslog – cooperation with the syslog server,
    Port Mirroring: monitoring or analyzing traffic on selected ports
    IEEE 802.3az: Energy Efficient Ethernet, reduced power consumption, 4 modes
    Port Trunk: IEEE 802.3ad LACP or static aggregation
    RMON, MIB II, Port mirroring, DNS, IEEE802.1ab LLDP, LLDP-MED
    MAC address table: up to 32k entries

    Network redundancy

    • ITU-T G.8032 Ethernet Ring (ERPS)
    • IEEE 802.1d – Spanning Tree (STP)
    • IEEE 802.1w – Rapid Spanning Tree Protocol (RSTP)
    • IEEE 802.1s – Multiple Spanning Tree Protocol (MSTP)
    • IEC 62439-3 Clause 4 and 5 support Ethernet Ring (HSR / PRP)
    Optional L3 – static routing
    ITU K.44 – built in TRX.1 modules on RJ-45 ports only in the transmission path secondary, 4kV, 10 / 700us overvoltage protections in accordance with the requirements of: “Resistibility tests for telecommunication equipment exposed to overvoltages and overcurrents – Basic Recommendation”
  • I/O interface - inputs
    Number of inputs – 4
    Input type – digital, potential-free
    Connector: screw
  • I/O interface - outputs
    Number of outputs – 2
    Type of outputs – relay NO / NC
    Maximum switching current – 0.5A 60VDC with resistive load
    Connector: screw
  • Device start-up time
    Full operability after a cold start after a maximum of 30 seconds.
  • MTBF
    Time: 650,000 hours
    Standard: Telecordia, SR-332
  • Management
    SNMP v1 / 2c / 3, SSH
    HTTP / HTTPS protocol – management via a web browser
    SSH v2, TELNET
    Local CLI console (RS-232)
    “Privilege level” – permission level configuration – read / write, independently configured for many users
  • REDBOX module
    Module that enables lossless network redundancy
    2x SFP slots – including 2x HSR/PRP ports supporting HSR (High-availability Seamless Redundancy) / PRP (Parallel Redundancy Protocol) for network redundancy and 1x RJ45 Ethernet Legacy port
    Support IEC 62439-3 Clause 4
    Support IEC 62439-3 Clause 5
    Supports IEEE 1588v2 PTP ( only available on 200.2)
    Transparency for transmission in PRP mode
  • GPS receiver for clock synchronization
    52-channel receiver cooperating with GPS, GLONASS, BeiDou, Galileo systems
    Antenna input with SMA connector and support for active antennas
    GPS receiver sensitivity: -165dBm/-160dBm
    Accuracy of GPS PPS signal: +/-30ns
    Possibility of equipping with stable on-board generators with various parameters:
    • OCXO generator with stability in the temperature range -40 to +85°C at the level of +/-20 ppb and holdover time in the range of ±1.5 µs for a minimum of 0.5 hours
    • OCXO generator with stability in the temperature range -40 to +85°C at the level of +/-2 ppb and holdover time in the range of ±1.5 µs for a minimum of 4 hours
    • OCXO generator with stability in the temperature range -40 to +85°C at the level of +/-0.2 ppb and holdover time in the range of ±1.5 µs for a minimum of 72 hours
    Supports support for IEEE 1588 v2 Precision Time Protocol
    Supports Synchronous Ethernet (SyncE) G.8261 support
  • Network synchronization
    The device is equipped with an on-board TCXO generator
    IEEE 1588-2008 v2 PTP – standard support for synchronization with the profile 1588
    • Transparent clock: peer to peer, end to end with one step, two step
      • Time error typically 50ns
    • Boundary clock
      • Time error for BC (Boundary clock) typically <200ns
    • Slave
    Optional synchronization with Power Profile IEEEC37.238-2011, IEEEC37.238-2017
    Optional also Synchronous Ethernet, G.8261: (Timing and synchronization aspects in packet networks)
  • Time synchronization I/O interface module
    Signal Input / Output 1PPS (One Pulse Per Second)
    10Mhz clock signal input / output
    ToD (Time-of-Day) input / output – the output can be reconfigured into an IRIG-B signal
  • Power
    DC 36-60V power supply
    DC80-360V power supply; AC 75-270V
    Optional two DC power inputs – redundant
    Screw connection for AC or DC power
    Total power consumption (without PoE ports) <40W
  • PoE power supply
    Compliant with IEEE802.3af, IEEE802.3at
    Power available for each port up to 90W
    For 55VDC power supply, the maximum total PoE power is 500W
  • Physical features
    Dimensions [141 mm or 183x135x120] mm
    Weight up to 2.5 kg
    Mounting DIN rail or free-standing
    Metal housing
  • Work environment requirements
    Working temperature: -40 to + 85 ° C with a minimum air flow of 0.4 m / s
    Working temperature: -40 to + 70 ° C with a minimum air flow of 0.0m / s
    The working time at the maximum temperature of + 85 ° C is up to 16 hours
    Standard operating ambient humidity: 0 to 95% (non-condensing)
    Location type: class C in accordance with PN-EN 60870-2-2 – sheltered locations
    Protection class in accordance with IP-30
